Specifications

• AC Socket
• IEC60320 C8(Small 2 pins) ADP193-31
• Input voltage: 100-240VAC
• Input frequency: 50/60Hz
• Output Voltage: 18.05-19.95V
• Output Current: 0-3.42A
• Ripple/Noise≤250mV
• Efficiency: ≥87% at full load
• Hold up time: ≥5ms
• Temperature range: Operating 0℃ to +40℃
• Output Watt: 65W
• Dimension:108*46*30mm(L*W*
  　

Compatibility:

• Dell Inspiron 300M, 500M, 505M, 510M, 600M, 630M, 640M, 700M, 710M, M101z, M5010R, M102z, M501R
• Dell Inspiron 1420, 1501, 1521, 1525, 1526, 1720, 1721,14V,15R, 14R,13Z,15Z
• Dell Inspiron 6000, 6400, 8500, 8600, 9200, 9300, 9400
• Dell Inspiron E1405, E1505, E1705
• Dell Latitude D400, D410, D420, D430
• Dell Latitude D500, D505, D510, D520, D530, D531
• Dell Latitude D600, D610, D620, D630
• Dell Latitude D800, D810, D820, D830
• Dell Precision M20, M60, M70
• Dell Vostro 1014, 1015, 1088, 3300, 3400

Key Features:

• Built-in protection: Over current protection, over voltage protection, short circuit protection
• More than 87% conversion efficiency
• Compatible with HP Notebook

Replace Adapter P/N :

• DELL PA-10, PA-12, NADP - 90KB, PA-1900-02D, PA-1900-02D2
