pecification

• VOLTAGE： 100～240VAC / 200～240VAC FULL RANGE(WITH ± 10% TOLERANCE, OUTPUT 1010W/1200W)
• FREQUENCY： 47～63HZ
• INPUT CURRENT (PER POWER MODULE)：15/7A FOR 115/230VAC
• INRUSH CURRENT (PER POWER MODULE)：60/80A MAX. FOR 115/230VAC (25℃)

Dimension

300x101.2x84(mm)
11.81x3.98x3.31(inch)

Featurs

• TEMPERATURE RANGE：OPERATING 0℃～40℃, STORAGE -20℃~80℃
• HOLD UP TIME：12mS MIN.
• DIELECTRIC WITHSTAND：INPUT/OUTPUT 1500 VAC FOR 1 MINUTE INPUT TO FRAME GROUND 1500 VAC FOR 1 MINUTE
• EFFICIENCY：>80% AT 115V, 20%~100% MAX LOAD.
• POWER GOOD SIGNAL：ON DELAY 100mS TO 500Ms
• OVER POWER PROTECITON: 110~160%
• OVER VOLTAGE PROTECTION：+3.3V→3.7V～4.1V，+5V→5.7V～6.2V ，+12V→13.3 V～14.3V
• OVER CURRENT PROTECTION: +5V→39~54A, +12V→107~147A, +3.3V→39~54A
• SHORT CIRCUIT PROTECTION: +5V, +3.3V, +12V, -12V
• REMOTE ON / OFF CONTROL
• REMOTE SENSING DESIGN
• BALANCE LOAD SHARING DESIGN
• HOT-SWAPPABLE/HOT PLUGGABLE REDUNDANCY FUNCTION
• ISOLATION: BUILT-IN THE POWER MODULE
• FAULTY ALARM METHODS: LED, BUZZER, TTL SIGNAL
• EMI NOISE FILTER: FCC CLASS B , CISPR 22 CLASS B
• MEET IEC-1000-3-2 CLASS D (ACTIVE PFC)
• SAFETY：TO MEET UL, TUV, CB IEC 60950

specification

• VOLTAGE： 100～240VAC / 200～240VAC FULL RANGE(WITH ± 10% TOLERANCE, OUTPUT 1010W/1200W)
• FREQUENCY： 47～63HZ
• INPUT CURRENT (PER POWER MODULE)：15/7A FOR 115/230VAC
• INRUSH CURRENT (PER POWER MODULE)：60/80A MAX. FOR 115/230VAC (25℃)

Dimension

300x101.2x84(mm)
11.81x3.98x3.31(inch)
