Zippy Micro Redundant Power 220w (ac/dc 1u) R1u2-5220v4h Psuzipr1u25220v4h
Special Price $622.00 Regular Price $716.00
| SKU: | 259194 |
|---|---|
| MPN: | PSUZIPR1U25220V4H Link |
| Manufacturer: | http://www.zippy.com.tw/zh-TW/index.aspx |
| Brand: | Zippy |
| Warranty: | Standard Manufacturer's Warranty |
| Availability: | In stock |
| Fright Estimate |
Description
▼
Featurs
- TEMPERATURE RANGE：OPERATING 0℃～50℃，STORAGE -20℃～80℃
- HOLD UP TIME：20mS MIN. AT FULL LOAD & 115 VAC INPUT VOLTAGE
- DIELECTRIC WITHSTAND：INPUT/OUTPUT 1500 VAC FOR 1 MINUTE
- EFFICIENCY：TYPICAL 78%(+/-2%) AT FULL LOAD 230VAC
- POWER GOOD SIGNAL：ON DELAY 100mS TO 600mS，OFF DELAY 1mS
- OVER POWER PROTECTION：110～170% MAX
- OVER VOLTAGE PROTECTION：+3.3V→3.6~4.3V, +5V→5.6~6.5V, +12V→13.2~15V
- SHORT CIRCUIT PROTECTION: +5V, +3.3V, +12V, -12V
- SAFETY：TO MEET UL, CUL, TUV, CCC
- FAULTY ALARM METHODS: LED, BUZZER, TTL SIGNAL
- MEET IEC-1000-3-2 CLASS D (ACTIVE PFC)
Specifications
▼
specification
- VOLTAGE： 90～264VAC FULL RANGE
- FREQUENCY： 47～63HZ
- INPUT CURRENT：2A（RMS）FOR 230VAC
- 4A（RMS）FOR 115VAC
- INRUSH CURRENT：35A MAX. FOR 115 VAC PER MODULE
- 70A MAX. FOR 230 VAC PER MODULE
Dimension
260x106x41.3(mm)
10.24x4.17x1.63(inch)
Vendor Info
▼
Featurs
- TEMPERATURE RANGEï¼OPERATING 0âï½50âï¼STORAGE -20âï½80â
- HOLD UP TIMEï¼20mS MIN. AT FULL LOAD & 115 VAC INPUT VOLTAGE
- DIELECTRIC WITHSTANDï¼INPUT/OUTPUT 1500 VAC FOR 1 MINUTE
- EFFICIENCYï¼TYPICAL 78%(+/-2%) AT FULL LOAD 230VAC
- POWER GOOD SIGNALï¼ON DELAY 100mS TO 600mSï¼OFF DELAY 1mS
- OVER POWER PROTECTIONï¼110ï½170% MAX
- OVER VOLTAGE PROTECTIONï¼+3.3V→3.6~4.3V, +5V→5.6~6.5V, +12V→13.2~15V
- SHORT CIRCUIT PROTECTION: +5V, +3.3V, +12V, -12V
- SAFETYï¼TO MEET UL, CUL, TUV, CCC
- FAULTY ALARM METHODS: LED, BUZZER, TTL SIGNAL
- MEET IEC-1000-3-2 CLASS D (ACTIVE PFC)
specification
- VOLTAGEï¼ 90ï½264VAC FULL RANGE
- FREQUENCYï¼ 47ï½63HZ
- INPUT CURRENTï¼2Aï¼RMSï¼FOR 230VAC
- 4Aï¼RMSï¼FOR 115VAC
- INRUSH CURRENTï¼35A MAX. FOR 115 VAC PER MODULE
- 70A MAX. FOR 230 VAC PER MODULE
Dimension
260x106x41.3(mm)
10.24x4.17x1.63(inch)
