Standard&Protocol
IEEE 802.3/IEEE 802.3u/IEEE 802.3ab/IEEE 802.3x/IEEE 802.3af/IEEE
802.3at
Indicator
16*Link/Act per device
16*PoE per device
1*Power per device
Interface
16 10/100/1000Base-T ports(Data/Power)
exchange capacity
32 Gbps
Packet Forwarding Rate
23.6Mpps
PoE supply management
Port 1-16 support IEEE802.3at/af PoE standard
PoE through pin
1 2 4 5 +
3 6 7 8 -
Input Voltage
AC: 100-240V~50/60Hz
Dimension
294*178*44mm ( W x D x H )
Power Consumption
in full conguration:<150W
PoE Max Power Supply:135W
Port Features
Standard: the switch functions as a common unmanaged switch and all the
ports of the switch can communicate with each other.
CCTV: the port cache is optimized and PoE ports 1-8 have higher
priorities over the other ports. All the ports of the switch can
communicate with each other.
VLAN: ports 1 to 14 are isolated from each other, but can communicate
with ports 15 and 16 (uplink ports) respectively.
Isolation: ports 1 to 8 and Ports 9 to 16 belong to two di erent
VLAN.This mode can be used to isolate supervision network and wireless
network to make them not interfere with each other.
Environment
Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
