Standard&Protocol
IEEE 802.3/IEEE 802.3u/IEEE 802.3ab/IEEE 802.3x/IEEE 802.3af/IEEE
802.3at
Indicator
24*Link/Act per device
24*PoE per device
1*Power per device
Interface
24 10/100/1000Base-T ports(Data/Power)
Packet Forwarding Rate
35.6Mpps
PoE supply management
Port 1-24 support IEEE802.3at/af PoE standard
PoE through pin
1 2 4 5 +/3 6 7 8 -
Input Power
AC: 100-240V~50/60Hz
Dimension
440*178*44mm( W x D x H )
Power Consumption
in full con guration: <250W
PoE Max Power Supply: 225W
Port Features
Standard: the switch functions as a common unmanaged switch and all the
ports of the switch can communicate with each other.
CCTV: the port cache is optimized and PoE ports 1-8 have higher
priorities
over the other ports. All the ports of the switch can communicate with
each other.
VLAN: ports 1 to 22 are isolated from each other, but can communicate
with ports 23 and 24(uplink ports) respectively.
Isolation: ports 1 to 12 and Ports 13 to 24 belong to two di erent
VLAN.This mode can be used to isolate supervision network and wireless
network to make them not interfere with each other.
Environment
Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
